UV Curable Ink

Image 1
PANCOLOUR INK Product UV Curable Ink

UV Curable Ink


COP28 ended in the UAE with the adoption of a historic resolution was finally passed calling for the world to "Transition away from all fossil fuels". According to the United Nations Intergovernmental Panel on Climate Change (IPCC), to maintain the safety bottom line of 1.5°C warming, emissions must be reduced by at least 43% in 2030 and 60% in 2035, based on 2019. At the same time, the government released the "12 Key Strategic Action Plans for Net-Zero Transformation", and energy saving has become a key indicator for various enterprises. Therefore, the curing method mainly based on UV lamps has gradually transformed from power-consuming UV mercury lamps to energy-saving UV lamps. Electric UV-LED lamp.

Pancolour has been mass-producing UV curable offset printing inks since 2008, providing Taiwan's printing industry with another MIT option besides imported inks. After more than 20 years of hard work, the quality of Pancolour's UV curable offset printing inks has been recognized by major domestic printing companies. At present, our current domestic energy-saving ink market share has exceeded 70%, and it has begun to sell overseas.

In recent years, Pancolour has actively developed various cost-effective materials through the mastery of core technologies, and successfully launched high-unit price energy-saving inks at the price of general UV inks. In the future, we will continue to research new materials to make the price of UV ink closer to that of traditional oil-based ink, and do our part to upgrade the printing industry.

Applications

Sheetfed Offset Printing Press

Rotary Offset Printing Press

Full Rotary Letterpress

Intermittent Rotary Letterpress Printing Press

Product Categories

LED curable ink for paper: CP series, CH series, SH series.

LED curable ink for plastic film ink: PNAD series.

UV curable ink for paper: SF series, NS series, DU series.

UV Curable ink for plastic film: LI series, CAV series.

Wavelength Operating Range

LED: 365nm/ 385nm/ 395nm/ 405nm

UV: 200nm-400nm

Series Products

Basic Colors

Process Yellow、Process Magenta、Process Cyan、Process Black、Violet、Warm Red、Green、White、Reflex Blue….etc.。


Additives

White Lake, Varnish, Compound Ink, Anti-scratch agent

Packaging type

Standard: 1Kg black plastic can, 12 cans per carton.

Others: Packaging materials and capacity can be specified according to customer's special needs.

Environmental Compliance

Free of mineral oil saturated hydrocarbons (MOSH) and mineral oil aromatic hydrocarbons (MOAH)

No issues with volatile organic solvents.

Fulfills ASTM F963-08 and EN 71 Part 3 specifications for heavy metal content.

Comply with RoHS and its amendments.

Certified by Sony as a Green Partner.

Storage conditions and usage notices

It must be stored in a cool indoor place with a temperature below 25°C and avoid direct sunlight. The shelf life is six months. Stir completely before use.

Applications

PANCURE® series of UV curable screen printing inks are specially designed for surface printing of various optical discs (CD/DVD/BD).

Product Performance

Excellent adhesion to a variety of protective lacquers and polycarbonate surfaces.
It has good thixotropic properties and is suitable for high-speed printing without screen leakage or ink dripping problems.
The low shrinkage properties of the ink allow printed discs to maintain acceptable mechanical/electrical properties before and after accelerated aging testing.
Optimized printability enables use on most optical disc printing presses.

Series Products

Basic Colors

Opaque White W100

Yellow DR202

Lemon Yellow DR203

Rubine Red DR313

Fire Red DR304

Rhodamine Red DR306

Mixing Base-M101

Orange DR307

Process Blue DR402

Violet DR403

Reflex Blue DR404

Black DR502

Green DR601


PMSR Colours

Refer to PANCURE® Mixing Formula Booklet, most colour mixing need would be satisfied.


Process Colours

Process Yellow 201M1

Process Magenta 301M

Clear Varnish OPV3000

Process Cyan 401M1

Process Black 501M1


Special Colour

Silver / Golden

Various colour shade, opacity, gloss/matte, and texture effects are available.


Colorful Series

Special colour sets according to customers request.


Printable

Thermal-Transfer printable

Suitable for most of commercial disc thermal printers.

Thermal Clear TPS105

Thermal White TW105

Thermal Silver TPS102

*Other Colours On Request


Ink-Jet Receptive ink

Clear PR888

PIJP-FD

PIJP-S23

PIJP-M1


Additives

Thinner 003 / Accelerator 005 / Thickener 006

Packaging type

Standard: 1Kg/5 Kg/10 Kg/20 Kg black PP can.
Others: Packaging materials and capacity can be specified according to customer's special needs.

Environmental Compliance

Contains no ozone-depleting substances.

No issues with volatile organic solvents.

Comply with RoHS, REACH environmental directive specifications.

Certified by Sony as a Green Partner.

Storage conditions and usage notices

It must be stored in a cool place and avoid contact with strong light or direct sunlight.

Stir completely before use.

Chemical Safety Instructions

Please refer to the Material Safety Data Sheet for details.
